Our ocean-class vessels feature twin screws with controllable pitch propellers (CPP), in nozzles and high lift rudders. Hulls are welded steel construction and each is outfitted for long-range ocean towing, firefighting and general purpose towing. The vessels are transverse framed with transverse and longitudinal bulkheads, including the collision bulkhead, which extends to the main deck. These boats were not only built for reliability, they were also designed with the environment in mind, with all tanks containing oil and oil traces placed inboard of the side shell to create a double hull designed to limit any overboard discharges. The vessel is flagged in the Registry of the United States of America and complies with all applicable rules and regulations.

Ocean Class Specifications

Specifications

FLAG

United States

PORT OF REGISTRY

Lake Charles, LA

BUILDER

Bollinger Shipyards
Amelia, LA

OVERALL DIMENSIONS

Length: 146’ (44.4 m)
             Ocean Wind/Ocean Wave
             156′ (47.5m)
             Ocean Sky/Ocean Sun
Breadth: 46′ (14.03 m)
Depth: 25′ (7.62 m)
Design Draft: 21’ (6.4 m)

TONNAGE

<1600 GRT

CONSTRUCTION

Steel

OPEN DECK SPACE

47′ x 45′ 2115 SQ2
13.71m x 14.32m 196.48 sq m2

FUEL CAPACITY

234,738 gallons (888.58 m3)
Ocean Wind/Ocean Wave
251,700 gallons (973.20 m3)
Ocean Sky/Ocean Sun

FUEL OIL OVERFLOW

2,118 gallons (8.02 m3)

DIRTY OIL

1,153 gallons (4.36 m3)

OILY WATER

1,225 gallons (4.64 m3)

HYDRAULIC OIL

570 gallons (2.16 m3)

FRESH WATER

19,060 gallons (72.15 m3)
Ocean Wind/Ocean Wave
24,700 gallons (93.5m3)
Ocean Sky/Ocean Sun

GRAY WATER

6,474 gallons (24.51 m3)

SEWAGE HOLDING

5,582 gallons (21.13 m3)

FOAM STORAGE

1,436 gallons (5.44 m3)

LUBE OIL

2,900 gallons (10.98 m3)

MAIN ENGINES

(2) Caterpillar C-280-12 Tier II*
Developing 10,880 (8,113kW) Total BHP

HARBOR GENERATOR

(1) 340kW Caterpillar C-18 Tier II*

EMERGENCY GENERATOR

(1) 125kW Caterpillar C-6.6 Tier II*

SHAFT GENERATORS

(2) 1,475 KVA
Ocean Wind/Ocean Wave
(2) KATO rated 1.5MW each
Ocean Sky/Ocean Sun

PROPELLERS

(2) 4-Blade Cu-Ni-Al CPP
153.5” (3.9 m) Diameter

NOZZLES

High Efficiency

REDUCTION GEARS

(2) Reintjes LAF 5666

SPEED

16 Knots

BOW THRUSTER

(1) Berg (Electric) VFD 850HP
Ocean Wind/Ocean Wave
(2) Berg (Electric) VFD 500HP
Ocean Sky/Ocean Sun

 STERN THRUSTER

(1) Berg 500HP  Ocean Sky/Ocean Sun

CRANES

Aft Deck 25T Capacity
Foc’s’le Deck Crane 5T Capacity

BOLLARD PULL

~ 150 MT
~ 165 ST

TOWING WINCH

Intercon – DW275 Hydraulic
Min. Holding Power 350 S.T. (317.51 MT)
500,000 lbs (226.80 MT) @ 20 Ft/Min
(6.1 m/Min)

 WIRE GUIDE PINS

200 MT Triplex

INDEPENDENT AUXILIARY WIRE DRUM

300′ of 1″ Wire rated @ 40,000 lbs
(18.14 MT) @ 100 Ft/Min (30.48 m/Min)
Independent Capstan
Rated @ 23,000 Lbs (10.43 MT) Line Pull @ 150 ft/Min (45.72m/Min)

 BOW WINCH

Intercon – VMS Winch
Electric Windless Mooring 1.25″ chain
Independent Capstan
Line Drum 600′ of 1.25″ Jacketed Plasma Line

TOWING WIRES

3,000′ (914 m) – 2.5″ (63.5 mm) Wire (Upper)
4,200” (1,219 m) – 2.75″ (69.85 mm) Wire (Lower)

SHARK JAWS

350 MT Triplex Quick Release

STERN ROLLER

6′ (1.83 m) Diameter

 ACCOMMODATIONS

13 total available
Three (3) 1 person staterooms
Five (5) 2 person staterooms

 *capable of being upgraded to Tier III or IV

Navigation / Communications Equipment

Radar

(2) Furuno FAR2117BB

GPS

(2) Northstar 952XD DGPS

GMDSS

Furuno RC1815 GMDSS

Autopilot

Robertson

Gyrocompass

Robertson

Depth Sounder

SOLAS Approved

Radios

(5) Furuno FM 3000

World Phone

Sailor (Thrane & Thrane)

EPIRB

(2) COSPAS-SARSAT 406MHz

 Dynamic Positioning

Kongsberg

Classification

A-1, Towing Service

AMS

ABS

ABS Firefighting Vessel Class 1

 ABS DP-1 Ocean Wind/Ocean Wave

 ABS DP-2 Ocean Sky/Ocean Sun

USCG Certificate of Inspection

Green Passport

SOLAS

International Load Line Certificate
